Shelving looks like the simplest job in the house. A board, a pair of brackets, four screws, done. Then the books go on, and within a month the shelf has developed a gentle sag, the plaster has crumbled around one fixing, and the whole run sits an inch proud of the wall at one end. Almost every failure traces back to a decision made before the drill came out. Here are the mistakes that cause the most trouble, and how to avoid each one.

Drilling blind where pipes and cables run

Before anything else, work out what is behind the plaster. Cables tend to run in straight vertical or horizontal lines from sockets, switches and ceiling roses. Pipes sit behind tiles, above radiators and in similar channels. A cable and pipe detector will not catch everything, but it catches most of it, and it costs far less than repairing a pierced heating pipe on a Sunday evening.

Treat these as warning zones:

• directly above and below sockets, switches and fused connection units
• horizontally between two sockets on the same wall
• directly above radiators, and behind basins and washing machines
• the narrow strips close to the ceiling and the floor, where joists and services often run

If the wall is plasterboard fixed to blockwork on dabs of adhesive, remember that the void behind the board is not empty space — it is where cabling lives. When in doubt, drill a small pilot hole and check before going deeper.

Working with an uneven wall instead of fighting it

Older houses rarely have walls that are flat, plumb and square all at once. Corners wander, plaster bulges, and a chimney breast can sit proud by 30mm. Measure from the floor and mark each bracket individually, and you will fit them perfectly to a wall that is not level — which means the shelf will show up every bump.

Establish one reference line instead. Mark a horizontal line with a long spirit level and take all your measurements from it. Where a bracket lands on a hollow, pack it out with a plastic packer or a sliver of timber so the face of the bracket stays flush with the line. For longer runs, fix a levelled batten to the wall first and hang the brackets from that; it is more forgiving and it spreads the load across more of the wall.

If a shelf has to sit tight against a wavy wall, scribe the end: hold it in place, run a pencil along the wall line, then plane or sand back to the mark. A 5mm gap looks like a mistake. A scribed end looks deliberate.

Fixings that do not suit the wall

The plug and screw that came in the box were chosen for the cheapest possible wall, and even that is optimistic. Match the fixing to the construction:

• Solid brick or blockwork: a masonry bit the same diameter as the plug, drilled slightly deeper than the plug is long, then a proper wall plug and screw.
• Mortar joints: avoid them where you can. The joint is softer than the brick and will not hold as well.
• Plasterboard over studs: find the timber with a stud finder or by tapping, and drive long screws straight into it. Studs are usually at 400mm or 600mm centres.
• Plasterboard with no stud where you need one: a metal cavity fixing or hollow wall anchor rated for the weight you intend to hang. A toggle fixing is the strongest of the hollow-wall options.

Drill the right size of hole. Oversized holes are a wobbly shelf waiting to happen.

Overloading and uneven weight

A shelf fails in one of two ways: the fixing pulls out of the wall, or the shelf itself bows. Both are fairly predictable.

The material matters. Chipboard and MDF cope with light loads but sag under sustained weight, especially over a long span in a warm room. Solid timber, birch plywood and purpose-made shelving boards hold their shape better. Respect any maximum span the manufacturer states, and if none is given, keep brackets closer together rather than further apart — roughly every 600mm is a sensible starting point for 18mm board.

Think about how the load sits, too. A row of hardbacks concentrates weight where it stands, so keep the heaviest items near the brackets rather than in the unsupported middle, and spread weight along the shelf instead of building one tower. Brackets are rated in pairs, and a pair of small ones will never carry what a pair of chunky ones will.

Spacing that suits what you are actually storing

Shelf spacing is where good shelving quietly becomes bad shelving. Too tight and half your things will not fit; too generous and you waste a wall. Measure the tallest items you plan to store, add a couple of centimetres of clearance, then work upwards.

• paperbacks and CDs: 25–30cm
• A4 folders, lever-arch files and box files: 35cm
• cookbooks and large hardbacks: 35–40cm
• cleaning bottles, laundry products and small appliances: 40–45cm
• ornaments and display items: judge by eye, but allow room to lift them in and out

Depth matters as well. Much beyond 30cm and things disappear to the back, never to be seen again. Finally, check the top shelf against your comfortable reach — a shelf you need a step stool for is a shelf you will stop using.

Where damp gets in

Damp is the slow killer of shelving, particularly in bathrooms, utility rooms, kitchens, garages and sheds. A shelf fixed tight to a cold external wall traps a thin layer of still air, and that is exactly where condensation forms. Over a winter, the back edge of the shelf and the wall behind it can turn black with mould, and the cardboard box stored there will quietly go soft.

A few habits help:

• leave a small gap between the back of the shelf and the wall so air can move
• avoid storing cardboard against cold external walls; use plastic crates or ventilated baskets instead
• choose powder-coated, galvanised or stainless fixings in damp rooms, since bare steel rusts and stains
• treat the room, not just the shelf: a working extractor fan and a window opened after a shower do more than any coating

MDF swells and crumbles once it takes on water, so keep it out of bathrooms and unheated outbuildings. If mould keeps returning, the moisture is coming from somewhere. Mould can affect your health, so if it is widespread or persistent, it is worth asking a surveyor or damp specialist to trace the cause before you spend money on new shelving.

A short checklist before you drill

1. Check for pipes and cables, and avoid the zones above sockets and radiators.
2. Identify the wall construction and choose fixings to match it.
3. Mark one level line and work from that, packing out any hollows.
4. Match the span to the shelf material, and keep heavy items near the brackets.
5. Space the shelves around what will sit on them, not around the height of the wall.
6. Leave a gap behind shelves on cold or damp walls.

Get those six things right and the shelving will outlast the paint. Get them wrong and you will be filling screw holes and starting again — usually with the same drill bit, on a Saturday afternoon you had earmarked for something else.
